Application
This full-automatic electromagnetic separator is widely used to remove iron powder, micro iron powderand magnetic material from ceramic, mining, chemical, electronic, food, new energy lithium battery materialand other industries. Specially for the separating of ceramic tiles raw material clay mud (temperature below60 degrees Celsius) developed and manufactured, operating simple and convenient.
Features
● Lower energy consumption, high magnetic field gradient, well-proportioned magnetic fields, and better iron removal result ;
● Using H grade high temperature electromagnetic ring, high insulation grade ;
● Automatic operation, no manual work needed,Conveniently and drastically to remove iron ;
● The iron removal is carried out by vibration motor assisted by external high pressure pump, which has no dead angle and no residue. ;
● The brake valve is using imported materials; there is no leaking, better wearable, lower air consumption;
● The magnetic media screen is using high performance stainless steel; the highest working magnetic fields up to 10000 gauss. there is no residual magnetism after switching off the excitation coil power supply,so it is easy to de-iron.
